| LG LUU097HV Capacity |
| BTU Class | 9,000 BTU |
| Heating Capacity | 14,000 BTU |
| Min Connectable Capacity | 3,600 BTU |
| Max Connectable Capacity | 9,900 BTU |
| LG LUU097HV General |
| AC System Type | Mini Split |
| Component Type | Outdoor Unit |
| Operation | Cooling with Heat Pump |
| Min No. of Connectible Indoor Units | 1 |
| Max No. of Connectible Indoor Units | 2 |
| LG LUU097HV Electrical Data |
| Power Source V / Hz / Ø | (208/230/60/1) |
| Running Current Cooling - Rated (Amps) | 9.65 Amps |
| Running Current Heating - Rated (Amps) | 9.65 Amps |
| Minimum Ampacity (Amps) | 11.9 Amps |
| Max. TD Fuse/Breaker | 15 Amps |
| Power Input Cooling - Rated (Watts) | 710 Watts |
| Power Input Heating - Rated (Watts) | 1,430 Watts |
| Rated Amps | 9.65 Amps |
| LG LUU097HV Performance |
| Compressor Noise Level - Cooling (dB) | 47 dB |
| Compressor Noise Level - Heating (dB) | 51 dB |
| Energy Star Certified | No |
| LG LUU097HV Piping Connections |
| Power and Communication Cable - No. | 4 |
| Power and Communication Cable - AWG | 18 |
| Liquid Line Outer Diameter | 1/4 Inch |
| Suction Line Outer Diameter | 3/8 Inch |
| LG LUU097HV Refrigeration System |
| Refrigerant Type | R-410A |
| Compressor Type | Twin Rotary |
| Refrigerant Control | EEV |
| Refrigerant Charge | 2.43 Ft. |
| Piping Length (No Additional Refrigerant) | 24.6 Ft. |
| Max. Line Length - Each | 66 Ft. |
| Max. Height Diff. btwn. Indoor and Outdoor Units | 49 Ft. |
| Outside Temperature Range for Cooling - Min. | 0 °F |
| Outside Temperature Range for Cooling - Max. | 118 °F |
| Outside Temperature Range for Heating - Min. | -4 °F |
| Outside Temperature Range for Heating - Max. | 64 °F |
| LG LUU097HV Features |
| Sleep Mode | Yes |
| Inverter (Variable speed compressor) | Yes |
| Low Ambient Operating Threshold (F°) | 0 |
| Corrosion Protection | Yes |
| No. of Fan Speeds | 3 |
| WiFi Connected | No |
| LG LUU097HV Technical Details |
| Voltage | 230/208 Volts |
| LG LUU097HV Dimensions |
| Width | 33 47/48 Inch |
| Depth | 13 11/12 Inch |
| Height | 21 23/48 Inch |
| Net Weight | 82 Lbs. |
| Shipping Weight | 89 Lbs. |
