| Jenn-Air JGC7530BP Appearance |
| Type | Cooktop |
| Style | Sealed Burner |
| Gas Type | Natural Gas |
| Jenn-Air JGC7530BP Features |
| Burners | 5 |
| Control Type | Knobs |
| Installs Over Oven | Yes |
| UL Certification | Yes |
| Continuous Grates | Yes |
| Dishwasher Safe Grates | Yes |
| Low-Profile Design | Yes |
| White LED Backlit Knobs | Yes |
| Cast Iron Grates | Yes |
| Jenn-Air JGC7530BP Technical Details |
| Color | Stainless Steel |
| Width | 30" |
| Fuel Type | Gas |
| Height | 4.5" |
| Volts | 120 Volts |
| Amps | 15 Amps |
| ADA Compliant | Yes |
| Cast Iron Grates | Yes |
| Control Location | Front |
| Frequency | 60 Hz. |
| Pro-Style | Yes |
| Convertible to Liquid Propane | Yes |
| Front Left Output | 12000 |
| Back Left Output | 12000 |
| Back Right Output | 5000 |
| Front Right Output | 9000 |
| Middle Center Burner | 12000 |
| Weight | 45.00 lbs |
| Jenn-Air JGC7530BP Dimensions |
| Exterior Width | 30" |
| Cutout Depth | 20.375" |
| Cutout Width | 29.375" |
| Depth | 21" |
