| Dacor DHW301 Appearance |
| Type | Hood |
| Style | Chimney Style |
| Venting Type | Ducted |
| Blower Type | Internal |
| Dacor DHW301 Features |
| Vent Location | Top |
| Duct Type | Round |
| Light | Yes |
| Light Bulb Type | Halogen |
| Number of Fan Speeds | 3 or More |
| Glass Canopy | No |
| Removable Baffle Filters | Yes |
| Baffle Filters | Yes |
| Electronic Control Panel | Yes |
| Made in Italy | Yes |
| Seamless Canopy | Yes |
| Dishwasher Safe Filters | Yes |
| Dacor DHW301 Technical Details |
| Color | Stainless Steel |
| Width | 30" |
| Volts | 120 Volts |
| Amps | 15 Amps |
| Dishwasher Safe Filters | Yes |
| Material | Stainless Steel |
| Mounting Type | Wall Mount |
| Filter Type | Baffle |
| Commercial | No |
| Frequency | 60 Hz. |
| UL | No |
| Fan | Yes |
| Usage | Residential |
| Recirculating Kit | No |
| Duct Diameter | 5.75" |
| Duct Location | Top |
| cUL | No |
| Minimum Height | 30" |
| Make-Up Air Compliant | No |
| Duct Cover Height | 29.5" |
| Number of Light Bulbs | 2 |
| Programmable Turn Off | Yes |
| Adjustable Duct Cover | Yes |
| Minimum Duct Cover Height | 17.5" |
| Electronic Speed Control | Yes |
| Weight | 61.00 lbs |
| Dacor DHW301 Dimensions |
| Height | 42" |
| Exterior Width | 30" |
| Depth | 24" |
| CFM | 600 CFM |
