| JennAir JXD7030YS Appearance |
| Type | Downdraft |
| Color | Stainless Steel |
| JennAir JXD7030YS Details |
| Duct Type | Both |
| Venting Type | Ducted |
| Blower Type | Internal |
| Vent Location | Side |
| CFM | 600 CFM |
| Number of Fan Speeds | 3 or More |
| Filter Type | Mesh |
| Fan | Yes |
| JennAir JXD7030YS Electrical Specifications |
| Volts | 120 Volts |
| Amps | 15 Amps |
| Frequency | 60 Hz. |
| JennAir JXD7030YS Certification |
| Energy Star | Yes |
| JennAir JXD7030YS Features |
| Luxury | Yes |
| Automatic Shut Off when Retracted | Yes |
| Reversible Box Motor | Yes |
| Four Fan Speed Settings | Yes |
| Hidden Slide Control | Yes |
| Aluminum Mesh Filters | Yes |
| JennAir JXD7030YS Technical Details |
| Weight | 93 lbs |
| JennAir JXD7030YS Dimensions |
| Exterior Width | 30" |
| Duct Diameter | 6" |
| Duct Length | 10" |
| Duct Width | 3.25" |
| Height | 28.875" |
| Depth | 20" |
| Width | 30" |
