| Miele DA6690DBRWS Appearance |
| Type | Hood |
| Venting Type | Ducted |
| Style | Chimney Style |
| Blower Type | Internal |
| Miele DA6690DBRWS Features |
| Number of Fan Speeds | 3 or More |
| Duct Type | Both |
| Vent Location | Top |
| Glass Canopy | No |
| LED ClearView Lighting | Yes |
| Dishwasher-Safe Grease Filter | Yes |
| 5 or 15 Minute Timed Programs | Yes |
| Vented Mode | Yes |
| Con@ctivity | Yes |
| Superior Energy Efficiency | Yes |
| Safety Shut-Off Control | Yes |
| Filter Indicator | Yes |
| Active AirClean Filter | Yes |
| Miele DA6690DBRWS Technical Details |
| Color | Brilliant White |
| Energy Star | No |
| Width | 35.375" |
| Volts | 120 Volts |
| Amps | 15 Amps |
| Approved for Outdoor Use | No |
| Light | Yes |
| Mounting Type | Island Mount |
| Filter Type | Mesh |
| Frequency | 60 Hz. |
| Warranty Terms | Limited 1 Year Parts and Labor |
| UL | No |
| Fan | Yes |
| Recirculating Kit | Sold Separately |
| Duct Diameter | 8.69" |
| cUL | No |
| Minimum Height | 27.75" |
| Make-Up Air Compliant | Yes |
| Number of Light Bulbs | 4 |
| Light Bulb Type | LED |
| Weight | 77.00 lbs |
| Miele DA6690DBRWS Dimensions |
| Exterior Width | 36" |
| Depth | 23.563" |
| Height | 39.563" |
| CFM | 625 CFM |
