| Viking RVCH336DG Appearance |
| Type | Hood |
| Style | Chimney Style |
| Venting Type | Convertible |
| Blower Type | Internal |
| Viking RVCH336DG Features |
| Vent Location | Top |
| Duct Type | Round |
| Light | Yes |
| Light Bulb Type | Halogen |
| Number of Fan Speeds | Variable |
| Automatic Turn On | Yes |
| Glass Canopy | No |
| Heat Sensor | Yes |
| Dishwasher Safe Filter | Yes |
| Dishwasher Safe Filters | Yes |
| Viking RVCH336DG Technical Details |
| Color | Damascus Grey |
| Width | 35.875" |
| Watts | 670 Watts |
| Volts | 120 Volts |
| Amps | 15 Amps |
| Mounting Height | 30-33" |
| Temperature Sensor | Yes |
| Mounting Type | Wall Mount |
| Filter Type | Mesh |
| Frequency | 60 Hz. |
| Warranty Terms | 1 Year Parts and Labor |
| UL | No |
| Fan | Yes |
| Recirculating Kit | Sold Separately |
| Duct Diameter | 7" |
| cUL | No |
| Duct Cover Width | 16" |
| Duct Cover Depth | 12" |
| Number of Light Bulbs | 2 |
| Adjustable Duct Cover | Yes |
| Minimum Duct Cover Height | 17" |
| Maximum Duct Cover Height | 30" |
| Weight | 56.00 lbs |
| Viking RVCH336DG Dimensions |
| Height | 12" |
| Exterior Width | 36" |
| Depth | 24" |
| CFM | 460 CFM |
