| XtremeAir DL09U48 Appearance |
| Type | Hood |
| Glass Canopy | No |
| Style | Standard Hood |
| Color | Stainless Steel |
| XtremeAir DL09U48 Details |
| Duct Type | Round |
| Venting Type | Ducted |
| Blower Type | Internal |
| Mounting Type | Under Cabinet |
| Vent Location | Top |
| CFM | 1600 CFM |
| Number of Light Bulbs | 4 |
| Light Bulb Type | LED |
| Number of Fan Speeds | 3 or More |
| Filter Type | Baffle |
| Fan | Yes |
| Light | Yes |
| XtremeAir DL09U48 Electrical Specifications |
| Volts | 120 Volts |
| Amps | 15 Amps |
| Frequency | 60 Hz. |
| XtremeAir DL09U48 Features |
| LED Lights | Yes |
| Stainless Steel Baffle Filters | Yes |
| XtremeAir DL09U48 Technical Details |
| Parts Warranty | 2 Years |
| Motor Warranty | 10 Years |
| Weight | 64 lbs |
| XtremeAir DL09U48 Dimensions |
| Exterior Width | 48" |
| Duct Diameter | 8" |
| Height | 18" |
| Depth | 21.5" |
| Width | 47.75" |
