| Zephyr AK9434AS Appearance |
| Venting Type | Ducted |
| Blower Type | Internal |
| Filter Type | Baffle |
| Zephyr AK9434AS Smart Features |
| Works with Brand Specific App | No |
| Works with Nest | No |
| Zephyr AK9434AS Features |
| Remote Controller | Included |
| Make-Up Air | Optional |
| Number of Fan Speeds | 3 or More |
| Made in USA | Yes |
| Bloom HD LED Bulbs | Yes |
| Electronic LCD Controls | Yes |
| Pro-Baffle Filters | Yes |
| ACT Airflow Control Technology | Yes |
| Wireless Remote Controller | Yes |
| Zephyr AK9434AS Technical Details |
| Color | Stainless Steel |
| Type | Cabinet Insert |
| Width | 34.375" |
| Control Type | Electronic LCD |
| Volts | 120 Volts |
| Amps | 15 Amps |
| Light | Yes |
| Mounting Height | 36" |
| Mounting Type | Under Cabinet |
| Frequency | 60 Hz. |
| Warranty Terms | 3 Years on Parts, 1 Year Labor |
| UL | Yes |
| Fan | Yes |
| Sound Level | 5.8 Sones |
| Vent Location | Top or Rear |
| Design Style | Pro Style |
| Recirculating Kit | No |
| Duct Diameter | 8" |
| Pro-Style | Yes |
| Duct Type | Both |
| cUL | Yes |
| Number of Light Bulbs | 2 |
| Light Bulb Type | LED |
| Programmable Turn Off | Yes |
| Duct Length | 3.25" |
| Duct Width | 10" |
| Weight | 40.00 lbs |
| Zephyr AK9434AS Dimensions |
| Exterior Width | 36" |
| Height | 12" |
| Depth | 22.5" |
| CFM | 715 CFM |
