| ZLINE 697I48 Appearance |
| Type | Hood |
| Venting Type | Ducted |
| Style | Chimney Style |
| Blower Type | Internal |
| ZLINE 697I48 Features |
| Number of Fan Speeds | 3 or More |
| Duct Type | Round |
| Vent Location | Top |
| Glass Canopy | No |
| 430 Stainless Steel | Yes |
| Stainless Steel Baffle Filter | Yes |
| ZLINE 697I48 Technical Details |
| Color | Stainless Steel |
| Width | 48" |
| Volts | 110 Volts |
| Amps | 15 Amps |
| Light | Yes |
| Mounting Height | 30" - 36" |
| Mounting Type | Island Mount |
| Filter Type | Baffle |
| Frequency | 60 Hz. |
| Warranty Terms | 3-Year Parts Warranty |
| Fan | Yes |
| Recirculating Kit | No |
| Duct Diameter | 8" |
| Number of Light Bulbs | 4 |
| Light Bulb Type | LED |
| Duct Length | 8" |
| Duct Width | 8" |
| Weight | 67.00 lbs |
| ZLINE 697I48 Dimensions |
| Exterior Width | 48" |
| Depth | 27.5" |
| Height | 12.5" |
| CFM | 700 CFM |
