| AGA TCDCLPMDAR Appearance |
| Gas Type | Liquid Propane |
| Cooktop | Sealed Burner |
| Drawer | None |
| AGA TCDCLPMDAR Cooktop Features |
| Highest Burner Output | 12000 BTU |
| Griddle | No |
| Grill | No |
| Cast Iron Grates | No |
| Continuous Grates | No |
| Downdraft Ventilation | No |
| Cooktop Control Type | Knobs |
| AGA TCDCLPMDAR Oven Features |
| Viewing Window | No |
| Double Oven | Yes |
| Convection | Yes |
| Self-Cleaning | No |
| Delay Bake | No |
| Steam-Clean | No |
| Oven Control Type | Knobs |
| AGA TCDCLPMDAR Technical Details |
| Color | Dartmouth Blue |
| Style | Freestanding |
| Width | 23.5" |
| Fuel Type | Dual Fuel |
| Burners | 4 |
| Volts | 240 Volts |
| BTUs | 35300 BTU |
| Amps | 30 Amps |
| Timer | No |
| ADA Compliant | No |
| Oven Racks | 3 |
| Primary Oven Capacity | 1.4 cu. ft. |
| Burners / Elements | 4 |
| Interior Width | 13.75" |
| Interior Depth | 19" |
| Interior Height | 8.5" |
| Broiler | Yes |
| Frequency | 60 Hz. |
| Warranty Terms | 1 Year Parts and Labor |
| Steam Oven | No |
| French Top | No |
| Dual Door | No |
| Front Left Output | 6150 |
| Back Left Output | 11000 |
| Back Right Output | 6150 |
| Front Right Output | 12000 |
| Secondary Interior Width | 13.625" |
| Secondary Interior Depth | 17" |
| Secondary Interior Height | 10" |
| Weight | 393.00 lbs |
| AGA TCDCLPMDAR Features |
| Sabbath Mode | No |
| Digital Temperature Display | No |
| Digital Clock | No |
| Convection Cooking | Yes |
| Sealed Burners | Yes |
| AGA TCDCLPMDAR Dimensions |
| Exterior Width | 24" |
| Height | 36" |
| Depth | 27.5" |
| Total Capacity | 2.7 cu. ft. |
